产品描述：
405nm Wavelength Stabilized Laser is a miniature collimated laser.
The stabilization is achieved by optical feedback using Locker,
external to the TO-can package for long lifetime operation.
产品特色：
➢ Single frequency,
➢ coherence length (~1m)
➢ Wavelength stability (4pm/ºC)
➢ Collimated TEMoo output
应用范围：
Raman spectroscopy, data storage, flow cytometry,metrology/interferometry,embossed holograms, CD
mastering, diffraction grating fabrication Confocal microscopy, particle counting,fluorescence, nondestructive testing,microlithography, high speed printing, lidar.

产品描述：
640nm Wavelength Stabilized Laser is a single mode, miniature laser in a standard TO package.
The laser has a very low temperature dependence and precise center wavelength over the locked region.
The narrow linewidth and long coherence length from a standard TO packaged laser enables many applications.
产品特色：
➢ Wavelength stability (<0.015nm/ºC)
➢ Single frequency
➢ Coherence length (>2m)
➢ Hermetically sealed
➢ Custom wavelengthsavailable
应用范围：
HeNe replacement, flow cytometry, metrology, bio instrumentation, graphic arts,Ramanspectroscpy,analytical instrumentation,sensing, and data storage.

产品描述：
658nm Wavelength Stabilized Laser is a single mode, miniature laser in a standard TO package. The laser has a very low temperature dependence and precise center wavelength overthe locked region.The narrow linewidth and long coherence length from a standard TO packaged laser enables many applications.
产品特色：
➢ Wavelength stability (<0.015nm/ºC)
➢ Single frequency
➢ Coherence length (>2m)
➢ Hermetically sealed
➢ Custom wavelengths available
应用范围：
HeNe replacement, flow cytometry, blood flow,metrology, bio Instrumentation, Graphicarts, Raman spectroscopy, analytical
instrumentation, sensing, and data storage

产品描述：
685nm Wavelength Stabilized Laser is a single mode, miniature laser in a standard TO package.
The laser has a very low temperature dependence and precise center wavelength over the locked region.
The narrow linewidth and long coherence length from a standard TO packaged laser enables many applications.
产品特色：
➢ Wavelength stability (<0.015nm/ºC)
➢ Single frequency
➢ Coherence length (>2m)
➢ Hermetically sealed
➢ Custom wavelengths available
应用范围：
Raman spectroscopy, flow cytometry, blood flow, metrology , bio instrumentation, graphic arts, analytical instrumentation,
sensing, and data storage .

产品描述：
780nm Wavelength Stabilized Laser is a single mode, miniature laser in a standard TO package.
The laser has a very low temperature dependence and precise center wavelength over the locked region.
The narrow linewidth and long coherence length from a standard TO packaged laser enables many applications.
产品特色：
➢ Wavelength stability (<0.015nm/ºC)
➢ Single frequency
➢ Coherence length (>2m)
➢ Hermetically sealed
➢ Custom wavelengths available
应用范围：
Raman spectroscopy, Speckle interferometry, bio-medical instrumentation, analytical instrumentation, metrology, and gas sensing .

产品描述：
785nm Wavelength Stabilized Laser is a single mode, miniature laser in a standard TO package.
The laser has a very low temperature dependence and precise center wavelength over the locked region.
The narrow linewidth and long coherence length from a standard TO packaged laser enables many applications.
产品特色：
➢ Wavelength stability(<0.015nm/ºC)
➢ Single frequency
➢ Coherence length (>2m)
➢ Hermetically sealed
➢ Custom wavelengths available
应用范围：
Raman spectroscopy, flow cytometry, metrology, bioinstrumentation, graphic arts, analytical instrumentation,
sensing, and data storage.

产品描述：
785nm, 500mW Wavelength Stabilized Laser is a multi-mode, miniature laser in a collimated 9mm TO package. The laser has a very low temperature dependence and precise center wavelength over the locked region.
产品特色：
➢ Spectral linewidth (0.15nm)
➢ Wavelength stability (0.01nm/ºC)
➢ Collimated 9mm TO-can package
应用范围：
Raman spectroscopy, sensing, metrology, medical, graphic arts , military, and analytical instrumentation.

产品描述：
785nm, 600mW Wavelength Stabilized Laser is a multi-mode, miniature laser in a butterfly, fiber-coupled package with integrated TEC.
The stabilization is achieved using the Locker .
The laser has a very low temperature dependence And precise center wavelength over the locked region.
产品特色：
➢ Spectral linewidth (0.15nm)
➢ Wavelength stability (0.01nm/ºC)
➢ 100um MM fiber Butterfly package
➢ Custom wavelengths available
应用范围：
Raman spectroscopy, sensing, metrology, medical, graphic arts,
military, and analytical instrumentation.

产品描述：
808nm Wavelength Stabilized Laser is a single mode, miniature laser in a standard TO package.
The laser has a very low temperature dependence and precise center wavelength over the locked region.
The narrow linewidth and long coherence length from a standard TO packaged laser enables many applications.
产品特色：
➢ Wavelength stability(<0.015nm/ºC)
➢ Single frequency
➢ Coherence length (>2m)
➢ Hermetically sealed
➢ Custom wavelengths available
应用范围：
Diode pumping, photodynamic therapy, bio-medical instrumentation, graphic arts, and analytical instrumentation.

产品特色：
➢ Output power：200mw
➢ Efficient quantum well structure
➢ Lower threshold current
➢ Center Wavelength：980nm
➢ Package：TO-18（Φ5.6mm）、TO-5（Φ9mm）

产品描述：
The DFB-1310-T5-6-A-A-A of Multi-Quantum Well (MQW) Distributed Feedback (DFB) lasers are well suited for low-cost high-speed transmitters.
The devices feature high output power, wide operating temperature range, and high side mode suppression.
Their uncooled, hermetically sealed, TO-56 style packages are a cost-effective means of providing a low-noise light source for intermediate-reach and long-reach digital transmission applications.
产品特色：
➢ Advanced Multiple Quantum Well (MQW) Distributed Feedback (DFB) Laser Design
➢ Cost-effective Uncooled Laser Technology
➢ SMSR typ. 40 dB
➢ 5.6-mm TO-style package
应用范围：
➢ CATV return path

产品描述：
The FP-1310-T5-6-2.5-W-A-A of Multi-Quantum Well (MQW) Fabry-Perot (FP) lasers are well suited for low-cost high-speed transmitters.
The devices feature high output power, wide operating temperature range, and high side mode suppression.
Their uncooled, hermetically sealed, TO-56 style packages are a cost-effective means of providing a low-noise light source for intermediate-reach and long-reach digital transmission applications.
产品特色：
➢ Advanced Multiple Quantum Well (MQW) Fabry-Perot (FP) Laser Design
➢ Cost-effective Uncooled Laser Technology
➢ 5.6-mm TO-style package
应用范围：
➢ CATV return path
➢ CATV Forward path
➢ CDMA Application
➢ WCDMA Application

产品描述：
The DFB-1550-T5-6-2.5-W-A-A of Multi-Quantum Well (MQW) Distributed Feedback (DFB) lasers are well suited for low-cost high-speed transmitters.
The devices feature high output power, wide operating temperature range, and high side mode suppression.
Their uncooled, hermetically sealed, TO-56 style packages are a cost-effective means of providing a low-noise light source for intermediate-reach and long-reach optical transmission applications.
产品特色：
➢ Advanced Multiple Quantum Well (MQW) Distributed Feedback (DFB) Laser Design
➢ Cost-effective Uncooled Laser Technology
➢ SMSR typ. 40 dB
➢ 5.6-mm TO-style package
应用范围：
➢ CATV return path
➢ CATV Forward path
➢ CDMA Application
➢ WCDMA Application

产品描述：
The FP-1550-T5-5-A-A-A of Multi-Quantum Well (MQW) Fabry-Perot (FP) lasers are well suited for lowcost high-speed transmitters.
The devices feature high output power, and wide operating temperature range.
Their uncooled, hermetically sealed, TO-56 style packages are a cost-effective means of providing a lownoise light source for intermediate-reach and longreach optical transmission applications.
产品特色：
➢ Advanced Multiple Quantum Well (MQW) Laser Design
➢ Cost-effective Uncooled Laser Technology
➢ 5.6-mm TO-style package
➢ -40° to 85° C operating temperature range
应用范围：
➢ CATV return path

产品描述：
The DFB-1650-T5-6-A-A-A of Multi-Quantum Well (MQW) Distributed Feedback (DFB) lasers are well suited for low-cost high-speed transmitters.
The devices feature high output power, wide operating temperature range, and high side mode suppression.
Their uncooled, hermetically sealed, TO-56 style packages are a cost-effective means of providing a low-noise light source for intermediate-reach and long-reach digital transmission applications.
产品特色：
➢ Advanced Multiple Quantum Well (MQW) Distributed Feedback (DFB) Laser Design
➢ Cost-effective Uncooled Laser Technology
➢ SMSR typ. 40 dB
➢ 5.6-mm TO-style package
应用范围：
➢ CATV return path

产品描述：
QL65F5S-A/B/C is a MOCVD grown 650nm band InGaAlP laser diode with quantum well structure.
It's an attractive light source, with a typical light output power of 10mW for optoelectronic devices such as Laser Pointer & Bar Code Reader.
产品特色：
➢ Optical Leveler
➢ Laser Pointer
➢ Bar Code Reader
应用范围：
➢ Visible Light Output : λp = 650 nm
➢ Optical Power Output : 10mW CW
➢ Package Type : TO-18 (5.6mmφ)
➢ Built-in Photo Diode for Monitoring Laser Diode

产品描述：
QL65I7S-A/B/C is a MOCVD grown 650nm band InGaAlP laser diode with quantum well structure.
It's an attractive light source, with a typical light output power of 30mW for optoelectronic devices such as DVD-R/+R, DVD-Recorder, High Speed DVD-player and Inderstrial Bar Code Scanner.
产品特色：
➢ Visible Light Output : λp = 658 nm(typ.)
➢ Optical Power Output : 30mW CW, 50mW PULSE(Tp = 0.5㎲, Duty = 50%)
➢ Package Type : TO-18 (5.6mmφ)
➢ Built-in Photo Diode for Monitoring Laser Diode
应用范围：
➢ Standard speed DVD-R/+R
➢ DVD-RW/+RW
➢ DVD-RAM

产品描述：
QL65J7S-A/B/C is a MOCVD grown 650nm band InGaAlP laser diode with quantum well structure.
It's an attractive light source, with a typical light output power of 50mW for optoelectronic devices such as DVD R/RW.
产品特色：
➢ Visible Light Output : λp = 660 nm(typ.)
➢ Optical Power Output : 50mW CW
➢ Package Type : TO-18 (5.6mmφ)
➢ Built-in Photo Diode for Monitoring Laser Diode
应用范围：
➢ DVD R/RW
➢ Optical Module
